Beam Column of Cylindrical Tube
D = mm t = mm Fy = MPa Section Information
Pf = kN kN.m Mfy = kN.m Loading Mfx =
End Moment Coefficient C m: 1). Cm = 0.85, for compression members in frames subject to joint translation (sideway) 2). Cm = 0.6 - 0.4 (M1 / M2) , for restrained compression members in frames braced against joint translation, not subject to transverse loading. M1 - the smaller moment, M1 / M2 is positive when the member is bent in reverse curvature 3). For compression members in frames braced against joint translation, and subject to transverse loading Cm = 0.85, for members whose ends are restrained Cm = 1.0, for members whose ends are un-restrained
Results kx. Lx/ rx = ky. Ly/ ry = Pf/(fc . Pn)+Cmx. Mfx / (fb . Mnx . ax)+Cmy. Mfy / (fb . Mny . ay) = Pf / (fc . Pn0) + Mfx / (fb . Mnx ) + Mfy / (fb . Mny ) =
Member Information Lx = mm mm Ly = Kx = Ky = Cmx = Cmy =
Beam Column of Cylindrical TubeReview Report
